Model No.: 12CBM Rear Loader Garbage Truck.
Overall Dimensions(LxWxH): 9,000×2,500×3,300mm.
Chassis Brand: Dongfeng.
Drive Type: 4×2.
Wheelbase: 5,000mm.
Engine Model: ISD210 50 Cummins.
Engine Power: 210HP.
Emission Standard: Euro 3.
Garbage Tanker Volume: 12CBM.
 |
 |
 |
 |
Description
BRIEF
The 12CBM rear loader garbage truck, manufactured by CSCTRUCK, boasts impressive features designed to enhance efficiency and minimize environmental impact. Built on a sturdy Dongfeng chassis with a 4×2 drive type, this vehicle is equipped with an ISD210 50 Cummins engine model, delivering 210 horsepower, and adheres to the Euro 3 emission standard, ensuring compliance with stringent environmental regulations.
At the heart of this rear loader garbage truck is its innovative design, comprising a sealed garbage compartment, hydraulic system, and operating mechanism. The fully sealed nature of the vehicle, combined with its self-compression and self-dumping capabilities, guarantees efficient waste management without the risk of secondary pollution. During the compression process, sewage is directed into a separate compartment, mitigating any potential inconvenience to the populace and ensuring a cleaner environment.
The incorporation of high-quality imported components further enhances the truck’s performance. These components are characterized by their high pressure, superior sealing properties, ease of operation, and safety, ensuring reliability and longevity even under demanding conditions.
Moreover, the 12CBM rear loader garbage truck offers customization options to meet varying needs. Customers can choose between a rear hanging bucket turning mechanism or a garbage bucket turning mechanism, tailoring the vehicle to specific operational requirements.
In summary, the 12CBM rear loader garbage truck from CSCTRUCK represents a significant advancement in waste management technology. With its robust construction, advanced features, and commitment to environmental stewardship, this vehicle sets a new standard for efficiency, cleanliness, and sustainability in the waste disposal industry.
FEATURES
1. Streamlined Waste Management Solution: Revitalize the appearance of city streets by rejuvenating the look of garbage cans, mitigating secondary pollution.
2. Enhanced Efficiency and Capacity: Achieve a crushing pressure of up to 12 tons with a loading capacity of 2 and a half times greater than traditional non-compressed garbage disposal methods.
3. Automated Operations: Employing a sophisticated computer control system, a single operator manages all loading and unloading tasks. Choose between fully automatic and semi-automatic modes, reducing labor intensity for sanitation workers and enhancing working conditions.
4. Cost-Effective Performance: Specialized equipment operates efficiently with automatic throttle control facilitated by the computer control system.
5. Dual Safety Assurance: Incorporating both computer-controlled and manual operation functions ensures heightened vehicle utilization and safety during operation.
6. Optional Turning Mechanism: Offer the flexibility of a turning mechanism for trash cans or buckets as desired.
SPECIFICATION
| Product Name | 12CBM Rear Loader Garbage Truck | Brand | CSCTRUCK |
| Cab | Flat Top | Engine Horsepower(PS) | 210PS |
| Overall dimensions(LxWxH)(mm) | 9,000×2,500×3,300 | Driving Style | Steering Wheel/Left Drive |
| Self-weight (Kg) | 11,000 | Loading Mass (kg) | 12,000 |
| Product Parameters (Main Configuration) | |||
| Item | Specification | ||
| Cab | D530 Cab Cummins 210 HP | ||
| Front Axle | 5 tons | ||
| Rear Axle | 10 tons | ||
| Gearbox | Shaanxi Fast 8-speed gearbox | ||
| Vehicle Rack | Straight through reinforced girder | ||
| Tire | 10.00R20 steel wire tires 6 pieces | ||
| Power Take-off Interface | Have | ||
| PTO | Have | ||
| Front/rear Overhang(mm) | Front: 1,430, Rear: 2,470 | ||
| Departure Angle | Front: 20, Rear: 17 | ||
| Suspension | Leaf spring 8/10+8. | ||
| Leaf Spring | 8 before, 10+8 after. | ||
| Number of axles | 2 | ||
| Wheelbase(mm) | 5,000 | ||
| Number of tires | 6 | ||
| Drive Type | 4×2 | ||
| Engine | ISD210 50 Cummins 210 horsepower | ||
| Emission Standards | Euro 3 | ||
| Suspension | Leaf spring | ||
| Driving Style | Steering wheel, left-hand drive. | ||
| Brake | Drum type. | ||
| Braking System | Air brake. | ||
| Spare Tire Rack | Have | ||
| Light | Have | ||
| Voltage | 24V | ||
| Color | According to user requirements. | ||
