Model No.: 18CBM Pure Electric Refrigerated Truck.
Chassis Brand: Geely Star Wisdom H8E.
Engine Model: Ningde Times Battery (LFP) 89.12 KWh.
Wheelbase: 3,360mm
Emission Standard: Pure Electric.
Refrigeration Range: -18 degrees
Refrigeration Unit: Songzhi SE-400 (-18 degrees)
 |
 |
 |
 |
Description
BRIEF
The Geely Starwise H8E is a pure electric 4-meter refrigerated truck equipped with a CATL (Contemporary Amperex Technology Co. Limited) LFP (Lithium Iron Phosphate) battery pack with a capacity of 89.12 kilowatt-hours. It features a permanent magnet synchronous electric motor that powers the vehicle. With its cutting-edge technology, this vehicle offers an impressive maximum driving range of 280 kilometers on a single charge.
The dimensions of the Geely Starwise H8E are 4,000 millimeters in length, 2,100 millimeters in width, and 2,100 millimeters in height. The vehicle’s interior boasts a spacious 18-cubic-meter storage capacity, making it ideal for transporting refrigerated goods. Its refrigeration system is capable of maintaining a chilly -18 degrees Celsius temperature, ensuring that perishable items are stored at the required low temperature during transportation.
In summary, the Geely Starwise H8E is a state-of-the-art electric refrigerated truck that combines a powerful 89.12 kWh LFP battery with a permanent magnet synchronous motor. With a maximum range of 280 kilometers, generous cargo space, and a reliable refrigeration system, it is a versatile and eco-friendly solution for transporting temperature-sensitive goods.
FEATURES
1. Zero Emissions: The “18CBM Pure Electric Refrigerated Truck” is entirely powered by electricity, making it an eco-friendly transportation solution. With zero tailpipe emissions, it helps reduce air pollution and greenhouse gas emissions, contributing to a cleaner environment.
2. Large Cargo Capacity: This refrigerated truck has a generous cargo capacity of 18 cubic meters (CBM), providing ample space to transport temperature-sensitive goods. Whether you’re moving perishable food products, pharmaceuticals, or other temperature-sensitive items, this truck offers ample storage space.
3. Precise Temperature Control: Equipped with a refrigeration system, this truck ensures precise temperature control for its cargo. It can maintain consistent and adjustable temperatures, making it ideal for transporting goods that require specific temperature ranges to stay fresh or preserved.
4. Quiet Operation: Electric vehicles are known for their quiet operation, and the “18CBM Pure Electric Refrigerated Truck” is no exception. Its electric motor produces minimal noise, which can be beneficial for urban deliveries and areas with noise regulations.
5. Low Operating Costs: Electric vehicles are generally more cost-effective to operate than their diesel or gasoline counterparts. With lower energy costs and reduced maintenance requirements, this refrigerated truck can offer significant long-term savings for businesses in the transportation and logistics industry.
SPECIFICATION
| ITEM | DESCRIPTION |
|---|---|
| Vehicle Model | 18CBM Pure Electric Refrigerated Truck |
| Chassis Brand | Geely Star Wisdom H8E |
| Body Length | 4,000mm |
| Engine | Ningde Times Battery (LFP) 89.12 KWh |
| Transmission | Permanent Magnet Synchronous Motor |
| Wheelbase | 3,360mm |
| Tires | 7.00R16 Vacuum Tire |
| Emission Standard | Pure Electric, Ningde Times, Factory-claimed Range of 280KM |
| Standard Features | Wide Single Cab, 7-inch LCD Instrument Panel, 8-inch Multimedia Screen, Reverse Radar, Rearview Camera, Electric Air Conditioning, Power Windows, Daytime Running Lights, Vehicle Connectivity, BCM Functions (Automatic Locking, Interior Lighting Delay Function, Interior Lighting Auto Off Function, Door Anti-theft Alarm), ABS, T-BXO |
| Dimensions | 5,995×2,260×3,265 mm (LxWxH) |
| Body Dimensions | 4,000×2,100×2,100 mm (LxWxH) |
| Gross Weight | 4,495 Kg |
| Curb Weight | 3,150 Kg |
| Payload | 1,150 Kg |
| Refrigeration Range | -18 degrees |
| Refrigeration Unit | Songzhi SE-400 (-18 degrees) |
| Optional Units | Kelly, Songzhi, etc. |
| Body Configuration | 1. Production Process: The body is manufactured using a vacuum adsorption and hydraulic adsorption integrated molding production line, with a sandwich composite bonding structure, and insulation performance meets national Class A standards. 2. Body Material: High-quality domestic fiberglass is used for the inner and outer wall panels (non-reflective, good heat insulation, strong hardness, oxidation resistance); the middle insulation layer uses high-density insulation board, and the body thickness is 8cm. The floor is made of an aluminum checker plate, and the door edge strip uses labyrinth-type rubber sealing strips. 3. Body Accessories: Aluminum alloy edge wrapping around the body, stainless steel corner wrapping, stainless steel door locks and hinges, stainless steel door frames and hinges, and energy-saving LED lighting inside the body. |
| Ventilation System | Optional bottom plate ventilation slots and ventilation partitions around the body for enhanced cooling air circulation for the refrigeration unit. |
| Optional Features | The interior floor can be equipped with ventilation slots, meat hook body frame reinforcement, top aluminum alloy guide rails, and stainless steel meat hooks. The Interior can be equipped with cargo securing devices, cargo suspension devices, interior cargo racks, insulated door curtains, etc. Temperature and humidity recorder: With on-board printing, high and low-temperature alarms, heaters, etc. |
