3.5-Ton Lifting Capacity Wheellift
Automatic Tire Clamping Device
Wireless Remote Operation Mode
JAC T8 4WD Pickup Chassis
JAC 150hp Diesel Engine
6 Speed Manual Transmission
![]() |
![]() |
![]() |
![]() |
Description
BRIEF
Pickup recovery trucks have been increasingly popular due to their simple yet effective design, compact appearance, and impressive power. They have become the perfect choice for towing and recovery in small and cramped spaces such as underground parking lots and garages.
In response to the growing demand for specialized recovery trucks, a new model of pickup recovery truck has been introduced. The 3.5-ton quick pick recovery truck has been specifically designed for small and lightweight towing operations in limited urban spaces.
This innovative vehicle boasts a short body and low-height design, which make it ideal for maneuvering in tight spaces where other types of recovery trucks would be unable to enter. Its compact size also makes it easier to transport and store, while still providing impressive towing capacity and power.
The 3.5-ton quick-pick recovery truck is equipped with advanced features that enable efficient and safe recovery operations. The pickup recovery truck’s powerful engine ensures reliable performance, while its specialized suspension system provides stability and control during towing.
In addition, the pickup recovery truck‘s compact design allows for easy access to confined spaces, and its specialized towing equipment ensures that pickup recovery trucks can be safely and securely transported without causing further damage.
Overall, the CSCTRUCK 3.5-ton quick-pick recovery truck is an excellent choice for anyone in need of efficient and reliable towing and recovery services in small or cramped urban spaces. With its impressive power, compact design, and specialized equipment, this pickup recovery truck is sure to meet the needs of even the most demanding recovery operations.
FEATURES
- Ability to be operated via wireless remote control.
- The automatic tire clamping mechanism.
- Ground clearance of 220mm.
- Dual airbags and knit seats.
- Cruise control for driving convenience.
- Reverse imaging and radar technology for enhanced safety.
- ESP body stability system to improve vehicle handling.
- Tire pressure monitoring system to help maintain optimal tire performance.
SPECIFICATION
Model |
RTT3.5HFC150L6 |
Chassis |
JAC T8 4WD LHD; JAC HFC4DB2-2E 150hp diesel engine; 6 speed manual transmission |
Cabin |
Crew cab; Rated nr. of passengers:2 front |
Overall Size |
5998×1880×1860mm (L×W×H) |
Wheelbase |
3380mm |
Front/Rear Wheel Tread |
1570mm/1570mm |
Front/Rear Overhang |
950/1668 mm |
Gross Vehicle Weight |
3235kg |
Tare Weight |
2400kg |
Front/Rear Axle Rating |
1510kg/1725kg |
Approach/Departure Angle |
31°/17° |
Max Speed |
150km/h |
Engine |
JAC HFC4DB2-2E, diesel engine; 4 cylinders in-line, 1.999L; Tier level VI emission |
Engine Output Power/Speed |
110Kw(150hp)/3600rpm |
Engine Output Torque/Speed |
310N·m/1800~2400rpm |
Transmission |
MT; Forward, 6 speed/Reverse, 1 speed |
Tires |
265/60R18; 4+1 spare tire |
Pickup Truck Standards |
Dual airbags, knit seats, cruise control, reverse imaging, radar, ESP body stability system, tire pressure monitoring |
Wheel Lift: |
|
Rated Capacity Fully Retracted |
3500kg |
Accessories: |
|
Auxiliary Wheel |
2nos |
Strap |
2nos |
