Model No.: 4×2 10Ton Refrigerated Delivery Truck.
Overall Dimension(LxWxH): 9,900/10,200×2,600×3,965mm
Chassis Brand: Foton Auman R Series.
Engine Model: Dongfeng Cummins B6.2NS6B260 Engine(260 HP).
Wheelbase: 5,750mm
Emission Standard: EURO VI.
Refrigeration Range: -18°C.
Refrigeration Unit: Kaixue 880.
 |
 |
 |
 |
Description
BRIEF
The Foton Auman R-Series refrigerated delivery truck is a versatile and efficient vehicle designed for the transportation of perishable goods while maintaining precise temperature control. With customizable engine options and a high-quality cooling system, this refrigerated truck is ideal for various industries, such as food logistics and pharmaceutical distribution.
1. Engine Options:
– The Foton Auman R-Series refrigerated delivery truck offers 3 engine choices to suit different performance requirements. Customers can select from engines with 220, 260, or 290 horsepower. This flexibility ensures the vehicle can efficiently transport goods over varying distances and terrains.
2. Transmission:
– Equipped with a Fast 8-speed gearbox, the truck ensures smooth and responsive gear shifting, enhancing overall performance and fuel efficiency.
3. Tires:
– The truck comes with 11R22.5 vacuum tires, known for their durability and grip, providing stability and control during transportation, even in challenging conditions.
4. Refrigeration Unit:
– The Foton Auman R-Series features a domestically manufactured Kaixue 880 refrigeration unit. This unit is capable of maintaining temperatures as low as -18 degrees Celsius, ensuring the safe and reliable transport of temperature-sensitive goods. Moreover, customers have the option to select other reputable brands and models for the refrigeration unit to meet their specific needs.
The Foton Auman R-Series refrigerated delivery truck combines performance, flexibility, and reliability, making it an ideal choice for businesses involved in the transport of perishable products. Whether it’s fresh produce, pharmaceuticals, or frozen goods, this vehicle can be tailored to meet various temperature-controlled shipping requirements. Its robust construction, powerful engine options, and adaptable refrigeration system make it a valuable asset in the logistics industry, ensuring the preservation of product quality during transit.
FEATURES
1. Payload Capacity: The Foton 4×2 10-ton refrigerated delivery truck is designed to handle a substantial payload of up to 10 tons. This feature makes it ideal for transporting large quantities of temperature-sensitive goods, such as perishable food items or pharmaceuticals.
2. Refrigeration System: This delivery truck is equipped with a robust refrigeration system that ensures precise temperature control. It can maintain the desired temperature range, ensuring the integrity and freshness of the transported products.
3. 4×2 Drivetrain: The 4×2 drivetrain configuration indicates that the truck has 2 axles, with power being delivered to one of the axles on each side. This setup provides good traction and maneuverability while optimizing fuel efficiency for urban and highway deliveries.
4. Spacious Cargo Compartment: The truck features a spacious cargo compartment, allowing for efficient storage and organization of goods. It is designed to accommodate various types of cargo, with customizable shelving and storage solutions to meet specific delivery needs.
5. Reliability and Durability: Foton is known for producing reliable and durable vehicles. The 10-ton refrigerated delivery truck is no exception, designed to withstand the demands of frequent and long-haul deliveries, making it a dependable choice for businesses in the transportation and logistics industry.
SPECIFICATION
| ITEM | DESCRIPTION |
|---|---|
| Vehicle Model | Foton 4×2 10Ton Refrigerated Delivery Truck |
| Chassis Brand | Foton Auman R Series |
| Body Length | 7,600mm |
| Engine | Dongfeng Cummins B6.2NS6B260 Engine (260 HP) |
| Transmission | Fast 8-speed |
| Wheelbase | 5,750mm |
| Tires | 11R22.5 Vacuum Tires |
| Emission Standard | EURO VI (National Emission Standard) |
| Chassis Standard | Auman 2200 Half Cab, Fast 8-speed, 11R22.5 Vacuum Tires, Aluminum Fuel Tank, EBP Multistate Switch, Air Conditioning, Vehicle Networking Terminal, Dash Cam, Central Locking + Power Windows + Remote Key, Cruise Control, MP3 Player, Airbag Seats. Engine options: 220 HP, 290 HP. |
| Exterior Dimensions | 9,900/10,200 × 2,600 × 3,965mm |
| Body Dimensions | 7,600/7,900 × 2,435 × 2,500mm |
| Gross Weight | 18,000 Kg |
| Curb Weight | 7,860 Kg, 8,075 Kg |
| Payload Capacity | 10,060 Kg, 9,795 Kg |
| Refrigeration Range | -18°C |
| Refrigeration Unit | Kaixue 880 |
| Optional Units | Domestic refrigeration units: Hanxue, Huatai, Shanghai Songhan, Kaili, K brand, and other well-known brands. Imported refrigeration units: American Carrier, Thermo King, South Korean Hanha, and other international brands. |
| Body Configuration | (1): The refrigerated truck uses a steel and wood structure, bridge-breaking heat insulation technology, galvanized pipe frame, high-quality fiberglass inside and outside (non-reflective, good heat insulation, strong hardness, oxidation resistance), filled with 8 thick XPS extruded polystyrene boards; high-strength adhesive, positive pressure machine hot pressing molding (using a fully automatic gluing press machine, gluing and pressing in one go, uniform gluing, not easy to bulge, efficient production). (2) The floor uses plastic pattern plates, the box interior side comes with aprons, right-angle edging on the box body, two drainage holes in the front, the door edge uses a labyrinth-style rubber sealing strip, and a bright stainless steel door frame. (3) Body accessories: Thickened aluminum alloy edge around the body, stainless steel corner guards, stainless steel door locks, hinges, hardware, and energy-saving LED lighting inside the body. |
| Ventilation System | Bottom ventilation groove, ventilation partition around the box. Enhance the cold air circulation effect of the refrigeration unit, and install ventilation grooves so that goods will not be in direct contact with the side walls and the bottom of the box. The ventilation groove is made of an aluminum alloy profile, with a simple and easy-to-clean structure. When transporting meat pharmaceutical products or box items, it is necessary to install ventilation grooves to prevent spoilage. |
| Optional Accessories | The interior floor can be fitted with ventilation grooves, reinforcing the body framework for meat hooks, top aluminum alloy guide rails, and stainless steel meat hooks. Interior options include cargo fixing devices, cargo hanging devices, interior shelves, insulation door curtains, etc. Temperature and humidity recorders: On-board printing, high and low-temperature alarms, heaters, etc. |
