54000 Liters tank capacity
Aluminum alloy 5182/5454 tank material optional
1-9 compartments of tank optional
13/16tons 4axles FUWA/BPW brand optional
12pcs 12R22.5 tires
Transporting liquid flammables gasoline, diesel
 |
 |
 |
 |
Description
SUMMARY
The 54000 liters aluminum fuel tank trailer offers several benefits over traditional trailers. Its lightweight design means that it requires less fuel to transport the same amount of cargo, resulting in increased fuel efficiency. Furthermore, it has a lower risk of damage in accidents due to its non-combustible materials. The trailer is also easier to maintain as it is made from less durable materials.
FEATURES
Safety
The aluminum tank trailer has a low center of gravity, making it easier to brake and safer to use. It is also made from non-combustible materials that generate less static accumulation, reducing the risk of sparks. This leads to less damage to the road, which helps to lower maintenance costs. Moreover, in the event of a collision, the trailer can absorb energy through deformation without sudden tearing.
Lightweight and High Payload
The reduction of self-weight increases the payload of the trailer, allowing it to transport the same amount of goods with fewer shifts.
Improved Fuel Efficiency
The aluminum tank trailer reduces carbon dioxide emissions, making it more environmentally friendly.
Long Service Life
The 54000 liters aluminum tank trailer has strong corrosion resistance, which results in a typical service life of 15-20 years.
Corrosion Resistance
The trailer has low maintenance costs due to its durable, easy-to-clean, and corrosion-resistant appearance, eliminating the need for painting.
High Recycling Value
The aluminum tank trailer has a high recycling value, making it an eco-friendly option even after its service life.
SPECIFICATIONS
|
Model |
CSC9501GYYA |
|
Capacity of Tank |
54000Liters + 3%~5% |
|
Compartment of Tank |
6 compartments |
|
Hauling for |
Liquid flammables(gasolines, diesel), Density 0.76 |
|
Overall Dimension |
13000x2500x3900mm(final size based on exact drawing) |
|
Material of Tank |
Aluminum alloy 5182/5454 optional |
|
Dished End of Tank |
Aluminum alloy 5182/5454 optional,7mm thickness, all single heads dished and flanged |
|
Material and Thickness of Shell of Tank |
Aluminum alloy 5182/5454 optional,7mm thickness |
|
Material and Thickness of Compartment of Tank |
Aluminum alloy 5182/5454 optional,6mm thickness |
|
Material and Thickness of Anti-wave Baffle |
Aluminum alloy 5182/5454 optional,5mm thickness |
|
Main Beam |
Standard heavy-duty frame welded on the bottom of the tank |
|
Roll-over Coaming |
Full-length roll-over coaming for anti-fall projection on both sides of the top of the tank |
|
Hydrostatic Test |
Pressure testing, hydrostatic @ 35kpa(5psi) each compartment of tank |
|
Painting |
All steel sandblasted and epoxy zinc phosphate primer and polyurethane finish painting(anti-corrosion) painted, with the client’s logo. |
|
Manhole Cover of Tank |
6 sets diameter 500mm anti-explosion safety manhole cover with breather valve |
|
Discharge Valve |
6 sets 3” ball valve for discharging, lockable box for discharge valve |
|
Bottom Valve(Emergency Valve) |
6 sets pneumatically controlled emergency valves, valve fitted with valve operator |
|
Hose and Hose Tray |
2pcs hose trays to fit 3” 6m hose |
|
Water Drain Pipe |
The water drain rubber pipe from the top of the tank provided |
|
Kingpin |
50# or 90# kingpin, 12mm thick mild steel plate fabrication |
|
Landing Gear |
1 set 28tons landing gear with two-speed manual operation type |
|
Axle |
4 sets of 13tons FUWA brand axles, with ABS |
|
Suspension |
4axis mechanical suspension |
|
Brake System |
Dual line air brake system comprising of contact type coupling, brake chamber, emergency valve and air reservoir |
|
Tires |
12R22.5, 12pcs+1spare |
|
Rims |
9.0*22.5 steel tubeless rims 12pcs |
|
Access Ladder |
A detachable steel ladder mounted at the rear of the tank |
|
Catwalk |
Anti-skid catwalk fitted with steel grating |
|
Safety Handrail |
Manual-operated collapsible handrail fixed on top of the tank |
|
Side Guard |
Steel side guards were provided on both sides of the tank |
|
Tool Box |
1set lockable toolbox |
|
Mudguard |
The whole piece of steel plates |
|
Rear Bumper |
Steel bumper with light assembly and number plates |
|
Fire Extinguisher |
2pcs 8kg dry powder fire extinguisher |
|
Anti-static System |
Earthing strip installed at the rear of the tank, 1pc grounding bounding reel |
|
Light and Wiring |
Standard front, side, and rear of the tank |
|
24v, 7 wires ISO socket |
|
|
Brake light, reverse light, direction indicator, LEF tail lamp |
|
|
8pcs side marker lamp |
|
|
Reflective Tapes and Sticker |
CSCTRUCK standard |
|
|
|
|
|
|
