Model No.: 6 Wheelers 6 CBM Road Sweeper.
Garbage Tanker: 4CBM + Water Tanker: 2CBM.
Overall Dimensions(LxWxH): 6,300×2,050×2,540mm.
Chassis Brand: JMC.
Drive Type: 4×2.
Wheelbase: 3,308mm.
Engine Model: Chaochai Diesel Engine, 4 Cylinders.
Engine Power(kW)/Horsepower(HP): 84kW/115HP.
Emission standard: Euro 3.
Sweeping width: 2.7-2.8m.
Max. driving speed(km/h): 90.
 |
 |
 |
 |
Description
BRIEF
Road sweeper truck, also known as street sweeper trucks, sweeper vehicles, road cleaner trucks, street cleaner trucks, road sweeper machines, street sweeper machines, sweeping trucks, road cleaning vehicles, municipal sweeper trucks, pavement sweeper trucks, plays a vital role in today’s municipal service!
The 6 wheelers 6 CBM road sweeper produced by CSCTRUCK represents a versatile and efficient solution for urban cleanliness and waste management. Built on a sturdy JMC chassis, this road sweeper boasts a 4×2 drive type, ensuring excellent maneuverability in urban environments. Powered by a reliable Chaochai diesel engine delivering 84kW/115HP of engine power, it guarantees robust performance while adhering to Euro 3 emission standards, thus minimizing environmental impact.
Equipped with a 6 cubic meter capacity, this road sweeper offers substantial debris collection capabilities, making it ideal for thorough street cleaning operations. With a sweeping width ranging from 2.7 to 2.8 meters, it can efficiently cover large areas, ensuring thorough cleaning in a single pass.
In addition to its road sweeping capabilities, this vehicle is designed for versatility, featuring a 4CBM garbage tanker and a 2CBM water tanker. This multifunctionality allows it to handle various waste management and street cleaning tasks effectively.
With a maximum driving speed of 90 km/h, this road sweeper ensures swift transit between cleaning sites, optimizing operational efficiency. Whether sweeping streets, collecting garbage, or watering green spaces, this vehicle provides a comprehensive solution for maintaining cleanliness and hygiene in urban areas.
The combination of robust construction, efficient performance, and multifunctionality makes the 6 wheelers 6 CBM road sweeper an indispensable asset for municipalities, sanitation departments, and urban cleaning contractors. It enhances the efficiency of street cleaning operations and contributes to the overall cleanliness and aesthetics of urban environments.
FEATURES
1. Achieve thorough cleaning with full suction power, eliminating the need for brush replacement and ensuring effortless maintenance without dust accumulation.
2. Attain flawless cleaning results, capable of removing debris ranging from tiny dust particles to regular pebbles and leaves effectively.
3. Equipped with a highly efficient filtration system for enhanced performance.
4. Boost cleaning productivity and minimize expenses: The efficiency of a single vacuum cleaner equals that of over 30 manual cleaners.
5. Ideal for various industrial settings including coal plants, power plants, cement plants, steel plants, and mining sites, among others.
SPECIFICATION
| ITEM | DESCRIPTION | ||
| Condition | New condition/Right-hand drive/4×2. | ||
| Chassis | Brand | JMC | |
| Curb weight(kg) | 2,300 | ||
| Wheelbase(mm) | 3,308 | ||
| Overall Dimensions(LxWxH)(mm) | 6,300×2,050×2,540 | ||
| Overhang (front/rear) (mm) | 1,032/1,868 | ||
| Wheel track (front/rear) (mm) | 1,506/1,404 | ||
| Approach/Departure angle(°) | 19/12 | ||
| Axle Load(kg) | 2,000/4,000 | ||
| Max. driving speed(km/h) | 90km/h | ||
| Tire | Specifications | 6 PCs with one spare tire. | |
| Number | 7.00R16. | ||
| Clutch | Reinforced diaphragm clutch. | ||
| Gearbox | Manual type, 6 Forwards & 1 Reverse. | ||
| Cabin | Left-Hand Driving, 2 Passenger Allowed, with A/C. | ||
| Engine | Model | Chaochai Diesel Engine, 4 Cylinders. | |
| Displacement(ml) | 3,856 ml/cc | ||
| Power(kW)/Horsepower(HP) | 84kW/115HP | ||
| Emission standard | Euro 3 | ||
| Brakes | Service brake: Dual circuit compressed air brake Parking brake: (Emergency brake): Spring energy, compressed air operating on rear wheels. Auxiliary brake: Engine exhaust valve brake. |
||
| Steering Gear | Power steering, hydraulic steering with power assistance. | ||
| Sweeping System | |||
| Tank | Garbage tank | Tank material | Stainless steel 304 |
| Tank volume(CBM) | 4 CBM | ||
| Water tank | Tank material | Stainless steel 304 | |
| Tank volume(CBM) | 1.5 CBM | ||
| Auxiliary engine | Model | ISUZU Engine 77HP | |
| Power(kW) | 57 kW | ||
| Brush | Quantity(pcs) | 4 pcs | |
| Working area(m) | 2.7-2.8 m | ||
| Remarks | 1, With water sprayer bar. 2, Rear vacuum cleaner. 3, Blower. 4, Rear LED pilot lamp. 5, Self unloading box body. 6, The color will be designed based on your requirements. |
||
