6-Ton Max Lifting Capacity Boom
6-Ton Max Rating Wheellift
Dual 4-Ton Capacity Planetary Winches
DONGFENG Dollicar D8 4X2 Truck Chassis
Yuchai 165hp Diesel Engine
WLY 6 Speed Manual Transmission
 |
 |
 |
 |
Description
BRIEF
For several years, CSCTRUCK has been operating in the recovery tow truck industry. CSCTRUCK’s vast experience in towing and recovery vehicles allows us to provide our customers with customized trucks for your business needs. We offer an 8-ton integrated recovery tow truck that is durable and robust, making it ideal for different working environments. The integrated tow truck also provides a safe and dependable performance that makes it effortless and efficient to clear wrecked vehicles from accident scenes. By choosing our service, you are guaranteed a professional and reliable solution that will meet all your towing and recovery needs.
FEATURES
Standard Features:
1. One car towing type.
2. Integral carriage.
3. Dual 4-ton hydraulic winch.
4. Haizhanli oil cylinder.
5. Hefei Wany hydraulic pump.
6. Italy Hyde hydraulic valve.
7. Zhejiang Jiashan power take-off.
Optional Features:
Hard fifth wheel plate and hard drawbar.
Hebei Weiguo oil pump.
Turkish Hele imported valve.
A long row of engineering warning lights (LED) (strobe/normal).
SPECIFICATION
|
Model |
INT08EQ165L6 |
|
Chassis |
DONGFENG Dollicar D8 4X2 Drive LHD; Yuchai YCY30165-60 165hp diesel engine; WLY6TS55 manual transmission |
|
Cabin |
Day cab; Rated nr. of passengers:3 |
|
Overall Size |
6950×2370×2410,2535mm (L×W×H) |
|
Wheelbase |
4400mm |
|
Front/Rear Wheel Tread |
1950mm/1860mm |
|
Front/Rear Overhang |
1745,1802,1820,1842,1765,1890mm/1630,1650,1800,1720mm |
|
Gross Vehicle Weight |
11995kg |
|
Tare Weight |
5850kg |
|
Front/Rear Axle Rating |
4350kg/7645kg |
|
Approach/Departure Angle |
21°/14° |
|
Engine |
Yuchai YCY30165-60, diesel engine; 4 cylinders in-line, 3L; Tier level VI emission |
|
Engine Output Power/Speed |
121kW(165hp)/2800rpm |
|
Engine Output Torque/Speed |
500N·m/1400-1800rpm |
|
Max Speed |
103km/Hour |
|
Transmission |
WLY6TS55 MT; Forward, 6 speed/Reverse, 1 speed |
|
Tires |
245/70R19.5, 8.25R20,245/70R19.5 16PR, 8.25R20 16PR, 8.25R20 14PR, 255/70R22.5 16PR; 6+1 spare tire |
|
Lifting System: |
|
|
Max Lifting Capacity |
6000kg |
|
Lifting Capacity at Full Extension |
3000kg |
|
Cylinder Telescopic Travel |
1540mm |
|
Basic Length of Boom |
3130mm |
|
Max Lifting Height |
3300mm |
|
Boom Lifting Angle |
3°~26.5° |
|
Sections |
2 |
|
Wheel Lift: |
|
|
Rated Capacity Fully Retracted |
6000kg |
|
Rated Capacity Fully Extended |
3500kg |
|
Effective Length of Arm |
2320mm |
|
Telescopic Travel |
1066mm |
|
Luffing Angle |
-4°~93° |
|
Winch: |
|
|
Winch Qty |
Dual |
|
Winch Type: |
Planetary |
|
Winch Capacity Each |
40kN |
|
Winch Cable Min Line Speed |
5m/min |
|
Winch Cable Diameter |
φ11mm |
|
Winch Cable Length |
3000mm |
|
Rear Outrigger Horizontal Span |
1400mm |
|
Hydraulic System |
Haizhanli oil cylinder, Hefei Wany hydraulic pump, Italy Hyde hydraulic valve, Jiashan power take-off |
|
Towing Accessories: |
|
|
Slide-In L-Arms |
1set |
|
Frame Forks |
1set |
|
Fork Receiver |
1set |
|
Chain Hook |
1nos |
|
Strap |
2nos |
|
Auxiliary Wheel |
2nos |
