Model：F3.8s3141
Emissions standards：EuroⅢ
Displacement（L）：3.76
Rated Power（kw/rpm）：105
Max torque （N.m/rpm）：450
 |
 |
 |
 |
Description
The technological requirements
welding
1. All welding parts should be cleaned of oil, rust and other dirt before welding
2. The height of the weld shall not be lower than the thickness of the base metal, and the welding strength shall not be lower than the strength of the base metal.
3. The welding shall be firm and reliable, and the weld shall be full, smooth, uniform and smooth. There shall be no weld defects such as false welding, welding leakage, welding nodus and pores
riveting
Riveting should be firm and reliable, rivets arranged neatly, rivet head is not allowed to have cracks, deflection, incomplete phenomenon, rivet head and parts surface must be close, not loose, leakage, water leakage
Bolt connection
The screw connection should be firm and reliable, the tightening torque should meet the requirements of JB/T6040, and the exposed length of the bolt should be 2 ~ 3 buttons.
adhesive
All joints are sealed with polyurethane sealant. The glue is uniform and continuous, and no glue residue is allowed to fall off.
paint
The total thickness of the outer surface paint film is ≥45μm, the light color is uniform, and there is no obvious flow mark and exposed bottom
