1. Our oil tank trucks are mobile diesel or petrol transporting trucks, available in stainless steel or carbon steel materials.
2. These trucks are mainly used for transporting oil, and some can also serve as refueling tank trucks with a refueling device.
3. Our company also produces oil tank trailers that can be manufactured according to European standards.
4. Tank material options include carbon steel, stainless steel, or aluminum alloy.
5. Heating pipes and insulation layers can be installed, with insulation material options including rock wool, glass wool, polyurethane foam, or aluminum silicate. The cladding can be customized.
6. Self-flow valves can be installed at the end or side of the tank.
7. Tank design can be customized as a single compartment or several compartments to transport different oils based on users’ needs.
Description
|
Vehicle Description |
Vehicle brand | Dongfeng |
| Vehicle type | Oil Tank Truck | |
| Drive form | 8×4 | |
| Overall dimension (mm) | 11990x2500x3600 | |
| G.V.W(kg) | 31000 | |
| Load capacity (kg) | 18400 | |
| Curb weight (kg) | 12470 | |
|
Chassis Description |
Chassis brand | Dongfeng |
| Axle load (kg) | 6500/6500/18000 | |
| F/R overhang (mm) | 1500/3090,1500/2690 | |
| Approach/Departure angle ( ° ) | 20/11 | |
| Tread (mm) | 2040 / 1860 | |
| Wheelbase (mm) | 2050+4000+1350,2050+4400+1350 | |
| Spring plate | 11 / 11 / – / – | |
| Tyre size & quantity |
12R22.5 18PR,295/80R22.5 18PR,315/80R22.5 16PR & 12+1 |
|
| Cab | One-and-a-half row | |
|
Engine Description |
Engine model | ISL9.5-292E51A |
| Displacement (ml) | 9460 | |
| Max power (kW) | 251 | |
| Horsepower (hp) | 340 | |
| Max speed (km/h) | 80 | |
| Emission standard | Euro 4 | |
| Type of fuel | Diesel | |
|
Tank Description |
Tank volume (m³) | 27.2 |
| Transport medium | Gasoline | |
| Density (kg/m³) | 700 | |
| Tank size (mm) | 9200x2350x1700 |
