ISUZU Runway Sweeping Vehicle 8 CBM

Model No.: ISUZU Runway Sweeping Vehicle 8 CBM.
Garbage container volume: 4 CBM + Clean water tank volume: 4 CBM.
Overall Dimensions(LxWxH): 7,160X2,250X2,750mm.
Chassis Brand: ISUZU.
Drive Type: 4×2.
Wheelbase: 3,815mm.
Engine Model: 4KH1CN5HS.
Engine power: 130hp.
Displacement: 2,999ml.
Emission standard: EURO V.
Maximum Speed: 110km/h.
Sweeping speed: 3-20 km/h.
Sweeping efficiency: ≥98%.
Max sweeping capacity: 60,000m2/h.
Max angle for discharging the garbage container: ≥54°.
Vice engine power: 140hp.
Water pump flow: 153L/m.
Max sweeping width: 3.5m.

BRIEF

Airport sweeper, also known as runway sweeper, apron sweeper, airfield sweeper, aircraft sweeper, tarmac sweeper, taxiway sweeper, ramp sweeper, aviation sweeper, jetport sweeper, and airstrip sweeper, is used in the field of aviation for maintenance and cleanliness.

The ISUZU 8 CBM runway sweeping vehicle, manufactured by CSCTRUCK, represents a cutting-edge solution for efficient and high-performance runway cleaning. This specialized vehicle boasts a 4×2 drive type, equipped with a powerful 4KH1CN5HS engine model that generates 130hp of engine power. Compliant with the EURO V emission standard, the vehicle ensures environmentally friendly operations while maintaining a remarkable 110km/h maximum speed on the runway.

Designed for optimal functionality, the sweeping vehicle comes with impressive features. The sweeping speed ranges from 3 to 20 km/h, ensuring meticulous cleaning at various intensities. With a sweeping efficiency of ≥98%, the ISUZU 8 CBM guarantees a thorough cleaning process. Its maximum sweeping capacity of 60,000m2/h further underscores its efficiency in handling large runway areas.

The vehicle is equipped with 4 CBM garbage containers, providing ample space for collected debris. The containers can be discharged at an impressive angle of ≥54°, facilitating easy and efficient disposal of the gathered waste. This design ensures that the cleaning process is not only effective but also streamlined for optimal operational convenience.

Moreover, the inclusion of 4 CBM clean water tanks adds an extra layer of versatility to the ISUZU 8 CBM sweeping vehicle. This feature enables the vehicle to perform not only efficient cleaning but also to maintain cleanliness standards by utilizing clean water during the sweeping process.

With a maximum sweeping width of 3.5m, this specialized vehicle from CSCTRUCK is tailored to meet the demanding requirements of runway maintenance. Whether it’s airports or other aviation facilities, the ISUZU 8 CBM runway sweeping vehicle stands out as a reliable, high-performance solution for maintaining pristine runway conditions.

FEATURES

1. Powerful Engine and Drive Type:
The ISUZU 8 CBM runway sweeping vehicle boasts a reliable 4KH1CN5HS engine model with 130hp engine power, ensuring efficient and powerful performance. Its 4×2 drive type enhances maneuverability, making it suitable for various sweeping tasks on runways and other surfaces.

2. Environmentally Friendly Emissions:
Complying with EURO V emission standards, the CSCTRUCK-produced sweeping vehicle is environmentally conscious, minimizing its impact on air quality. This feature not only ensures regulatory compliance but also reflects a commitment to sustainability and eco-friendly operation.

3. High Sweeping Efficiency and Capacity:
With a sweeping efficiency of ≥98%, the vehicle guarantees thorough cleaning of surfaces, removing debris and contaminants effectively. The impressive maximum sweeping capacity of 60,000m2/h further enhances productivity, making it suitable for large-scale cleaning operations on runways and other expansive areas.

4. Versatile Waste Management System:
Equipped with 4 CBM garbage containers and 4 CBM clean water tanks, the sweeping vehicle is designed for versatile waste management. The ≥54° maximum angle for discharging the garbage container ensures efficient and controlled disposal, while the clean water tanks contribute to dust suppression, maintaining a cleaner working environment.

5. Optimal Performance and Speed:
The 4KH1CN5HS engine, combined with the 4×2 drive type, enables the sweeping vehicle to reach a maximum speed of 110km/h, facilitating quick and efficient transportation between cleaning sites. With a sweeping speed range of 3-20 km/h and a 3.5m maximum sweeping width, the vehicle is adaptable to various cleaning scenarios, ensuring optimal performance in different conditions.

SPECIFICATION

1. General Specification

2. Chassis Specification

3. Sweeping Specification

4. Washing Specification
