IVECO 32M Aerial Platform Fire Truck - Truck Manufacturer & Supplier

Model No.: CSCAPFT032.
Max. working height: 32M.
Rescue Basket: Max. 300kg Load Capacity.
Overall Dimensions(LxWxH): 9,750X2,500X3,750mm.
Chassis Brand: IVECO.
Drive Type: 4×2.
Full Load Weight: 18,000kg.
Max. Speed: 90km/h.
Engine Power: 206kW.
Fire monitor flow rate: 80L/s.
Shooting Range: 70m.

Description

BRIEF

The IVECO 32M aerial platform fire truck, produced by CSCTRUCK, is a state-of-the-art emergency response vehicle for firefighting and rescue operations. Equipped with a robust IVECO chassis, this truck features a 4×2 drive type and a full loading weight of 18,000 kg, making it highly durable for challenging terrains and urban environments. It boasts a powerful 206 kW engine, enabling a maximum driving speed of 90 km/h, ensuring fast deployment in emergencies.

One of the key highlights of the IVECO 32M is its 32-meter maximum working height, which allows it to effectively access high-rise buildings and other elevated structures for rescue and fire suppression tasks. The aerial platform also supports a rescue basket with a 300 kg load capacity, allowing the safe evacuation of individuals from difficult-to-reach locations. This platform’s versatility makes it essential for complex fire-fighting scenarios and rescue missions in high-rise buildings, industrial complexes, and disaster zones.

The fire truck also has an advanced fire monitor that can deliver a flow rate of 80L/s, providing significant water coverage during fire suppression operations. The monitor’s impressive 70-meter shooting range allows the crew to combat fires from a safe distance, which is critical for minimizing exposure to hazardous conditions. Designed for both urban and rural firefighting needs, the IVECO 32M aerial platform offers a combination of strength, speed, and reliability, making it a valuable asset to fire departments and emergency response teams. Its cutting-edge technology and operational efficiency make it an essential tool for saving lives and protecting property in fire emergencies.

FEATURES

1. High Working Height: The fire truck is equipped with a 32-meter maximum working height, allowing for effective aerial firefighting and rescue operations at significant heights.

2. Rescue Basket Load Capacity: The truck’s rescue basket can carry up to 300kg, providing ample capacity for rescuing individuals or carrying equipment during emergency operations.

3. IVECO Chassis with 4×2 Drive: Built on a reliable IVECO chassis with a 4×2 drive type, the vehicle offers stable handling and maneuverability, ideal for navigating various terrains during fire and rescue operations.

See also Foam Dry Powder Fire Truck 4x4

4. Powerful Performance: Featuring a 206kW engine, the fire truck has a strong performance to drive at speeds up to 90 km/h, ensuring quick deployment in emergency situations.

5. Advanced Firefighting Capabilities: The fire truck is equipped with a fire monitor capable of delivering a flow rate of 80L/s and can shoot water or foam up to a range of 70 meters, enhancing its firefighting efficiency even at a distance.

SPECIFICATION

32 Meters IVECO Rescue Aerial Platform Fire Fighting Truck

No.	Main Items	Technical Parameters
1.1	Model	CSCAPFT032
1.2	Overall Dimensions(LxWxH)	9,750×2,500×3,750mm
1.3	Full Load Weight	18,000kgs
1.4	Number of the Crew	2 (include driver)
1.5	Max. Speed	90km/h
1.6	Capacity	Optional
1.7	Fire pump flow rate	Optional
1.8	Fire monitor	80L/s flow rate and 70m shoot range
1.9	Max. working height	32 meters

2. IVECO Chassis

No.	Main Items	Technical Parameters
2.1	Manufacturer	IVECO
2.2	Model	Optional
2.3	Drive Type	4×2
2.4	Wheelbase	Optional
2.5	Engine model	Optional
2.6	Engine type	Inline 6-cylinder, turbocharged, intercooled diesel engine.
2.7	Rated power	206kW
2.8	Gearbox form	Manual
2.9	PTO	Full power sandwich type
2.10	Fuel tank capacity	200L aluminum fuel tank
