Model No.: JMC 164HP Refrigerated Lorry 19 CBM.
Overall Dimension(LxWxH): 5,995mm x 2,270mm x 3,255mm.
Chassis Brand: Jiangling Xinkaiyun.
Engine Model: Jiangling 164 HP, 3000 ml Displacement.
Wheelbase: 3,360mm
Emission Standard: EURO VI.
Refrigeration Range: Lowest -18°C.
Refrigeration Unit: Domestic/Imported.
 |
 |
 |
 |
Description
BRIEF
The JMC 164HP refrigerated lorry 19 CBM, sporting the official model JX5049XLCTGA26, boasts a robust JMC 164 horsepower engine with a displacement of 3,000mL. Complementing its power, it features a JMC 6-speed gearbox and rolls on 7.00R16 steel wire tires. The cargo compartment, measuring 4,020×2,100×2,100mm, offers ample space with a total volume extending to 18.5 cubic meters.
Efficiency meets versatility as the refrigeration unit can be tailored to individual preferences, accommodating either domestic or imported models. This adaptability extends to its impressive cooling capabilities, achieving a minimum temperature of -18 degrees Celsius. The truck is not merely a means of transportation but a reliable partner for transporting goods that require precise temperature control.
The integration of cutting-edge technology ensures that the JMC 164HP refrigerated lorry 19 CBM stands out in its class. The 164-horsepower engine delivers not only power but also fuel efficiency, making it a sustainable choice for businesses aiming to optimize their logistics operations. The 6-speed gearbox enhances overall performance, providing a smooth and responsive driving experience.
Safety is a priority with the inclusion of 7.00R16 steel wire tires, offering stability and durability on various terrains. The cargo compartment’s dimensions are carefully designed to accommodate a diverse range of goods, emphasizing the truck’s adaptability to different transport needs.
In conclusion, the JMC 164HP refrigerated lorry 19 CBM exemplifies a harmonious blend of power, efficiency, and adaptability. Whether navigating urban landscapes or traversing challenging terrains, this truck stands as a reliable choice for businesses seeking a dependable and versatile solution for their refrigerated transportation needs.
FEATURES
Brand: JMC is a Chinese automobile manufacturer that produces a variety of commercial vehicles, including trucks, vans, and buses.
Engine: 164HP refers to the horsepower of the lorry’s engine. Horsepower is a measure of an engine’s power, and a higher horsepower rating means that the engine is more powerful.
Type of vehicle: A refrigerated lorry is a type of truck that has a refrigerated compartment for transporting temperature-controlled goods, such as food and pharmaceuticals.
Cargo capacity: 19 CBM refers to the cargo capacity of the lorry. Cargo capacity is a measure of how much cargo a vehicle can carry. CBM stands for cubic meters, and 19 CBM is approximately equivalent to 670 cubic feet.
Suitable for: Transporting temperature-controlled goods. This refrigerated lorry is suitable for transporting goods that need to be kept at a specific temperature, such as food and pharmaceuticals.
SPECIFICATION
| ITEM | DESCRIPTION |
|---|---|
| Vehicle Model | JMC 164HP Refrigerated Lorry 19 CBM |
| Chassis Brand | JMC |
| Box Length | 4,020mm |
| Engine | Jiangling 164 HP, 3000 ml Displacement |
| Transmission | 6-Speed |
| Wheelbase | 3,360mm |
| Tires | 7.00R16LT 10PR |
| Emission Standard | EURO VI |
| Standard Features | Jiangling Xinkaiyun, Cab Width 2060mm, 3.0L Engine, 164 HP, 6MT Transmission, Air Brake, Chassis Weight 2.25T, 120L Fuel Tank, Remote Key, Daytime Running Lights, Multifunction Steering Wheel, Power Windows, Cruise Control, Electric Heated Mirrors, 5T Rear Axle, Air Deflector, Reverse Radar, Factory Dual Supports for Refrigeration Unit, Factory Dual Batteries, Factory 150A Alternator, Refrigerated Truck PTO with One-Button Cooling. |
| Dimensions (External) | 5,995mm x 2,270mm x 3,255mm |
| Dimensions (Box) | 4,020mm x 2,100mm x 2,100mm |
| Gross Weight | 4,490Kg |
| Curb Weight | 3,200Kg |
| Payload | 1,095Kg |
| Refrigeration Range | Lowest -18°C |
| Refrigeration Unit | Domestic/Imported |
| Optional Units | Carrier, Huatai, Hanxue, Han-ya, Kaixue, American Carrier, American Thermo King, etc. |
| Box Configuration | Utilizes the latest insulated bridge-breaking process. The box structure is made of galvanized pipe frame, environmentally friendly waterproof wooden boards connected by screws, with 8cm insulation in between, inner and outer fiberglass, high-strength adhesive, heat-pressed, 304 stainless steel frame, thickened aluminum profile edge wrapping, 27 stainless steel door locks, accessories. The box is assembled without glue, is seamless, and has fast cooling, slow heat dissipation, and a good insulation effect. The door has a bevel, and the sub-beam is a one-time fold of 510 I-beam steel, locked with a press plate, side guardrail, and rear bumper are formed at once and secured with screws. |
| Ventilation System | Optional bottom plate ventilation slot and ventilation partitions around the box enhance the cold air circulation of the refrigeration unit, after installing the ventilation slot, the goods will not be in close contact with the box side walls and the box bottom, the ventilation slot is made of aluminum alloy profiles, simple structure, easy to clean. To transport meat medical supplies, or cargo items, you need to install a ventilation slot to prevent spoilage. |
| Optional Accessories | Inside the box, you can install a ventilation slot, strengthen the frame of the meat hook compartment, top aluminum alloy guide rail, and stainless steel meat hook. Inside the box, you can install cargo fixing devices, cargo hanging devices, interior shelves, insulated door curtains, etc. Temperature and humidity recorder: with on-board printing, high and low-temperature alarms, heaters, etc. |
