SHACMAN 12000 Liters Water Tank Truck

12,000Liters tank capacity
304 stainless steel tank material
Used for transporting drinking water
Best Weichai engine and transmission adopted
Water tank welded by machine automatically
High-quality painting for hot and cold weather

Description

BRIEF



Water tanker trucks produced by CSCTRUCK serve a vital role beyond just delivering drinking water to communities; they are also crucial in transporting recycled rainwater to farmlands suffering from drought. These trucks provide a reliable water source, essential for sustaining irrigation systems that keep crops growing and livestock healthy, even in the harshest conditions. By ensuring that water reaches these drought-stricken areas, water tanker trucks help farmers maintain their livelihoods, preventing devastating losses during prolonged dry spells. Their ability to deliver water where it’s most needed makes them an indispensable tool for farmers, helping to safeguard their agricultural operations and sustain food production in challenging climates. In times of severe drought, these trucks become a lifeline, supporting the resilience of farms and the communities that depend on them.



FEATURES



1. Professional Specialized

With more than 20y/o producing experience on all kinds of tankers, capacity from 3,000Liters to 30,000Liters.

See also  FOTON 10,000Liters Milk Tanker Truck

2. Multi-function

Wildly used in drinking water transportation, farming, construction, and road situations.

3. Top Standard of Producing Procedures Adopted

Tank manufacturing automation production line has developed advanced tank manufacturing technology from steel plate stamping, sheet metal milling, plate butt jointing, coiling, forming, assembly, welding, forming, and other processing steps, and is equipped with automatic manufacturing equipment for each process. The main beam is cut by a laser cutting machine, and the height and thickness are determined according to the load capacity and road conditions.

4. Quality Guaranteed

All truck chassis and parts we adopted are original and came from popular G7 countries. We never use any false or high-imitation trucks and parts. We each production process listed and the material used in the specification we follow strictly. We NEVER reduce any process and use inferior material during truck production. All Tankers were tested by air, water, X-ray, and fire-firing.



SPECIFICATION



Model

WT11SX270L6

Truck Brand

Shacman/SX1189LA1F1C

Overall Dimensions(LxWxH)

7,530×2,500×3,200(mm)

GVW/Curb Weight

18,000(Kg)/6,400(Kg)

Capacity of Tank

11,600 Liters

Compartment of Tank

3 compartments, inner with anti-surge baffles in the tank

Drive Style

4×2, LHD/Rhd optional

Cabin

Shacman L3000 cabin, white color, Day cabin, with radio, USB, A/C,3seats

Wheelbase

4,000mm

Engine

Weichai brand, WP6H270E61, 270HP Euro 6 standard

Transmission

FAST brand, 8JS85TE-C, 6F+2R, manual type

Tires

10.00R20 18PR

F/R Axles

6.5/11.5T

Clutch

Single, dry clutch

Brake

Pneumatic brake

Electrical System

24V

Fuel tanker

Steel tank

Shape of Tank

Oval tank

Material of Tank

High-quality mild steel

Thickness of Tank

4-5mm

Used For Medium

Diesel and gasoline

Flow Meter

1pc, oval gear flow meter, 12~100m3/h of normal flow range, reading head with totalizer

PTO

1pc, high-quality side-power driven PTO

Manhole

3pc, Euro. standard

Emergency Valve

Pneumatic controlled emergency valve

Discharging Valves

1pc., high-quality ball valves

Toolbox

1pc, CSCTRUCK standard

Sucking System

6.5m of sucking dept., <6m of sucking time, 2pcs of sucking hoses

Cat Walkway

Antiskid plate type, installed on top of the tank

Handrail

Used to rise & drop type, fixed on top of the tank

Carries of Hoses

2pcs., installed on each side of the tank

Standard Parts

Toolbox, climbing ladder

Painting

Shot blasting pre-treated, sandblasting processing of tank, anti-corrosion treated internal of tank, advanced polyurethane painted on the surface of the tank.
